FF-S-200B
17 AUGUST 2004
SUPERSEDING
FF-S-200A
October 24, 1969
FEDERAL SPECIFICATION
SETSCREWS: HEXAGON SOCKET AND
SPLINE SOCKET, HEADLESS
The General Services Administration has authorized the use of this
federal specification by all Federal agencies.
1. SCOPE AND CLASSIFICATION
1.1 Scope. This specification covers hexagon socket and spline socket
headless setscrews.
1.2 Classification.
1.2.1
Types. Setscrews shall be of the following types, as specified
(see 6.2).
Type I - Hexagon socket, headless.
Type II - Spline socket, headless.
1.2.2
Styles. Setscrews shall be of the following styles, as specified
(see 6.2).
Style
1
-
Flat point.
Style
2
-
Cone point.
Style
3
-
Oval point.
Style
4
-
Cup point.
Style
5
-
Full-dog point.
Style
6
-
Half-dog point.
1.2.3
Size. Setscrews shall be classified by size in accordance with
the basic major diameter of the thread (see 6.2).
1.2.4
Length. Setscrews shall be of the length specified in 6.2.
Comments, suggestions, or questions on this document should be addressed to: Defense
Supply Center Philadelphia, ATTN: DSCP-ITAA, 700 Robbins Avenue, Philadelphia, PA
19111-5096 or emailed to dscpg&ispeccomments@dla.mil. Since contact information can
change, you may want to verify the currency of this address information using the
ASSIST Online database at www.dodssp.daps.mil.
AMSC N/A
FSC 5305
